Efflorescence Damaged Quarry Tiled Hallway Renovated in Cambridgeshire

Posted on August 9, 2019 by AbzDominise

This quarry tiled floor in the village of Gamlingay had been subject to efflorescence salt staining over many years. This problem typically occurs in older houses where the floor has been laid without a damp-proof membrane allowing moisture to rise through the tile bringing with it salts from the sub floor. Gamlingay is located in South Cambridgeshire, near the border with Bedfordshire, is an ancient village which features in the Domesday Book. Not surprisingly a lot of the property here is quite old and includes sixty listed buildings.

Salt Stained Quarry Tiled Hallway Floor Before Cleaning

Before the current owner moved in the property had been left dormant and empty with no heating which hadn’t helped the condition of the floor amongst other things. The white efflorescent salt staining was now very evident on the Quarry tiles and had caused a lot of damage to the surface of the floor. I discussed with the client how we could help and carried out a test clean. They were happy with the result and we agreed our quote to renovate the floor. We arranged to return later in the month.

Renovating a Salt Damaged Quarry Tiled Hallway Floor

The cleaning began with the application of Tile Doctor Remove and Go which was sprayed onto the tile and left to soak in for about ten minutes. The tiles were then scrubbed with a very coarse 200-grit diamond pad fitted to a rotary machine. The soil was then extracted using our van mounted hot water extraction system which makes light work of rinsing the floor and keeps the mess to a minimum. The combination of Tile Doctor Remove and Go and the coarse pad cleaned and resurfaced the tile improving the appearance of the floor and once the soil was removed you could really see the transformation.

We finished the cleaning process by giving the whole floor an acid wash using Tile Doctor Acid Gel. The acid dissolves the alkaline salt still present in the floor and removes any grout haze still present on the tile. Once this had been scrubbed in it was rinse off and extracted using the hot water extraction system as before. The floor was then left to dry out which due to the lack of damp-proof membrane was expected to lake longer than usual, so we decided to leave the floor a few days.

Sealing an Old Quarry Tiled Hallway Floor

We returned on a nice sunny day and first tested the floor with our damp-proof meter. This just tests the moisture levels in the floor to check they are to an acceptable level. If the floor is not dry the seal will not cure properly, and the process would be a waste. In this case the readings were fine, and I was happy the floor was dry enough to be sealed.

The client had requested the floor have a low sheen appearance and they didn’t want it to look too shiny. Given the floors history with Efflorescence however I needed to choose a sealer that would give the desired appearance but was also fully breathable and allow for moisture to rise through the tile. Trapping moisture under the tile with a non-breathable sealer can result in moisture spreading to the walls leading to rising damp.

On this occasion I opted to go with the application of Seal and Go extra which is fully breathable and leaves a subtle sheen appearance. The acid wash we gave the tiles should neutralise the alkaline salts and now the house was occupied the damp issues which had led to them occurring in the first place are less likely. I applied six coats of sealer, allowing each one to dry before applying the next.

Salt Stained Quarry Tiled Hallway Floor After Cleaning

As you can see from the pictures, the work made a dramatic difference to the floor and my client was delighted with the transformation.

Source: Quarry Cleaning and Renovation Service in Cambridgeshire

Renovating a Quarry Tiled Hearth in Wilmslow, Cheshire

Posted on April 1, 2019 by AbzDominise

We received an inquiry from a client in Lindow End near Wilmslow Golf Club in the Cheshire stockbroker belt. They were restoring their home and were unhappy with the state of the Quarry tiled hearth under their log burning stove. We arranged a site visit to survey the tile and grout and provide a quote for restoring the appearance. The village is situated in what’s known as the ‘Cheshire Golden Triangle’ which is one of the most sought-after places to live in the UK after London. As a result, we often find ourselves in this area working on some very nice properties, so it wasn’t long before we were able to call in and survey the tiles.

Quarry Tiled Hearth Before Grout Colouring Lindow End

As you can see from the pictures the hearth was quite dirty and the grouting had discoloured from years of use of the wood burner. The work here was a minor part of their restoration which had included significant building work. We agreed a price to carry out the work, which should only take a day and were able to return the following week.

Cleaning a Quarry Tiled Hearth

Our first job was to cover the newly sanded and sealed wooden floors with dust sheets, so we didn’t mark them as we came in the front door to the lounge. We always try and make as little mess as possible and we are always as careful as possible.

We then sprayed Tile Doctor Pro-Clean on the fire hearth tiles. This is a multi-purpose tile and grout cleaner which would make light work of the dirty tiles. The product was left to soak into the Quarry tile and grout for about twenty minutes before being scrubbed in. The hearth was a small area, so this was done by hand and then washed down with clean water.

The dirty residue was removed using a wet vacuum then the tiles where wiped down with a clean micro fibre cloth. We then dried off the tiles using a little encouragement with a heat gun to speed up the drying process. Speed drying the tile and grout in this manor would allow us to complete the work in one visit.

Applying Sandstone Grout Colourant

Once the tiles and grout lines were dry it was clear that years of dirt and soiling had stained the grout, so although no much cleaner it was clear more work would be needed to give the grout a fresh and consistent appearance.

To address this issue with the grout we selected to apply a Sandstone Tile Doctor Grout Colourant. This is applied with a small brush and brushed it into the grout lines. It is quite a precise job but any colourant that goes onto the tiles is removed with a baby wipe before it dries. This process really transformed the look of the grout, the colourant also forms a barrier over the grout which will protect it going forward and make it easier to clean.

Sealing Quarry Tiles

The Quarry tiles were then given a coat of Tile Doctor Colour Grow which is an impregnating colour enhancing sealer. This brings out the best in the quarry tiles and adds protection against future staining which will be needed given its location.

Quarry Tiled Hearth After Grout Colouring Lindow End

The client was very happy with the finish, in fact the hearth looked like it had been newly tiled, the impact of the recoloured grout was that striking. Sometimes the smallest jobs can be the most rewarding.

Source: Quarry Tile Cleaning and Restoration Service in Wilmslow, Cheshire

Removing Paint and Candle Wax from an old Quarry Tiled Floor in Knaresborough, North Yorkshire

Posted on March 21, 2019 by AbzDominise

This is an original Chequered Black and Red Quarry Tiled floor at a house in the historic town of Knaresborough. The town expanded rapidly during Victorian times and this floor dates to when the house was built over 100 years ago. The properties in the road are all a similar style and age so it’s likely that there are others with original Quarry tiled floors too.

Quarry Tiled Floor Before Cleaning Knaresbrorough

Before contacting us, the customer had already spent a week trying to clean the floor and was not happy with the result. He emailed over some pictures to highlight the problems which mainly related to paint splashing from decorating. I reviewed the pictures and subsequently made a site visit to survey the floor. It was clear that he had managed to make the floor cleaner, but more work was required. Confident l could improve upon his efforts we set a date for my return.

Removing Paint Spots from a Quarry Tiled Floor

I spent the first morning carefully scraping off spots of plaster and candle wax that l knew my machine wouldn’t remove. Once that was done, I gave it a good scrub using a black pad fitted to a rotary buffer and using Tile Doctor Pro-Clean diluted with three parts water. The resulting slurry was then rinsed off the floor with water and extracted using a wet vacuum.

This was an old floor with no damp proof membrane, and I was concerned white efflorescence salts would appear as the floor dried out. To counter this I gave the floor an acid rinse with Tile Doctor Acid Gel to help neutralise and inhibit any alkaline salts. After scrubbing it into the floor with a deck brush I rinsed the acid off the floor and again extracted the waste using the wet vacuum. I took some damp meter readings at that point and found that surprisingly the floor was only showing a 20% moisture reading. I left the floor to dry out fully overnight and would check the damp readings again the next day before sealing.

Sealing a Quarry Tiled Floor

I had the option of sealing it the next day or the day after, so I decided to leave my damp meter with the customer, so he could take the readings himself and let me know when the floor was dry. He took some more readings four hours later which were lower and after discussing it with me on the phone later that evening I agreed to return the following day. I took some more readings the next morning and most of the floor was reading less than 10% which was an improvement but not as good as I had hoped for. I decided to spend some time speed drying the tiles with a heat gun to be sure.

Once I was happy, I applied two coats of Tile Doctor Colour Grow to enhance the colour and protect the tiles from staining. This gave the floors a lovely sheen and the deep colour looked great. Colour Grow is an impregnating sealer that works by occupying the pores in the tile thereby preventing dirt from becoming ingrained there. This sealer is also fully breathable which means it will allow moisture to rise through the floor which is important on these old floors with no DPM.

Quarry Tiled Floor After Cleaning Knaresbrorough

The full renovation process dealt with all the issues my customer has raised and the new sealer gave the floor a very consistent appearance. I’m happy to confirm that my customer was pleased with results and is now content that his floor is in the best condition it could be considering its age.

Source: Quarry Tile Cleaning and Sealing Service in Knaresborough, North Yorkshire

Dealing with Efflorescence on Quarry Tiles in Goostrey, East Cheshire

Posted on February 28, 2019 by AbzDominise

Pictured below is an old Quarry tiled floor in the Kitchen of a house in the small farming village of Goostrey. I went over to survey the floor at the request of the owner who felt it was overdue a deep clean and seal.

Quarry Tiled Kitchen Floor Before Cleaning Goostrey

It was a classic floor that suited the kitchen and its Aga well however I’m sure it could tell a story. There were patches of white efflorescent salts in front of the Aga itself and another section of floor where the tiles were a slightly darker shade. I assume some replacements were made in this section at some point in the past. Efflorescence occurs when damp in the subfloor rises through the tiles depositing white alkaline salts on the surface of the tile as the moisture evaporates. This is quite a common problem in older properties where no damp proof membrane is present under the floor and more so where you have a warm Aga heating the space and encouraging evaporation.

As per usual the floor was survey noting all the points above and then I carried out a test clean on a small part of the floor. This helps me understand what products and process I need to follow in order to renovate the floor and thereby product an accurate quote for the work. This went well and the owner was happy for us to process so we agreed a date to start the work which would take two days.

Cleaning a Quarry Tiled Floor

To clean the floor and strip off any remaining sealer I first created a strong dilution of Tile Doctor Remove and Go which was sprayed onto the tiles and then left to soak in. Remove and go is a powerful stripper and cleaner that is safe to use on tile and stone. The product is designed to loosen paint stains, adhesives and many types of urethane and wax coatings so they can be easily removed.

After thirty minutes the solution was scrubbed into the tile and grout using a weighted rotary machine fitted with a black scrubbing pad and running at a slow speed. The resulting cleaning slurry was rinsed off with water and then extracted from the floor using a wet vacuum. I repeated this process until I was confident the tiles were clean and free of old sealer.

The next step was to neutralise the alkaline salts in the floor which could later lead to efflorescence by treating it to an acid wash using Tile Doctor Acid Gel. The gel was left to soak in for five minutes before washing it off using the wet vacuum to get the floor as dry as possible.

Quarry Tiled Kitchen Floor During Cleaning Goostrey

Sealing a Quarry Tiled Floor

The floor was left to dry out overnight and the next morning I returned to the property and took some readings from the floor with a damp meter. It’s important to check the floor is dry before sealing because any excess moisture can cloud the sealer and prevent it from doing its job properly.

Once satisfied that the floor was dry, I applied a single coat of Tile Doctor Colour Grow which is a breathable impregnating sealer that enhances colour and protects from within. I left the floor to dry for one hour and then followed up with four coats of Tile Doctor Seal and Go which provides both a robust surface seal and a long-lasting low sheen finish. The new sealer transformed the tiles and gave the whole floor a uniform appearance

Quarry Tiled Kitchen Floor After Cleaning Goostrey

The customer was very impressed with our work and asked if we can come back later to remove the white tiles in front of the Aga and replace with Quarry tiles to match the rest of the floor.

Source: Quarry Tile Cleaning and Sealing Service in Goostrey, East Cheshire

Extending and Restoring a Quarry Tiled Hallway Floor in Blakedown, Worcestershire

Posted on December 14, 2018 by AbzDominise

We received an enquiry requesting we take a look extending a Quarry Tiled hallway floor at a property in Blakedown which is a small village in the Wyre Forest District of North Worcestershire. The house had an extension to the front of the property added previously which increased the size of the hallway however this had not been tiled to match the existing, simply backfilled with screed.

Quarry Tiled Floor Extension Blakedown Kidderminster Before

The owner had decided to have the extension floor tiled to match the existing Quarry tiled floor which would also need renovating due to it being covered in part with a variety of paint, glue and screed. Whilst most of our work is repairs and cleaning my background in tiling means I’m also able to lay new tiled floor so this job was a perfect match for my skills.

I arranged a site visit to view the floor as it is difficult to tell from the photos the work that would be needed. The floor would require extensive restoration and then extending into the extension so after visiting the property and assessing what was required, I wrote out a detailed quote and the quote was accepted. We booked a date in to complete the works which would be carried out over a few days.

Cleaning and Extending a Quarry Tiled Hallway Floor

The first job was to break up the existing screed that the builder had laid in the extension. It was a lot of work, so I enlisted the help of Mick Gayton the Warwickshire Tile Doctor. Together we broke up the screed, removed the rubble and then used Bal self-levelling compound to prepare the surface for tiling.

Quarry Tiled Floor Extension Blakedown Kidderminster Removing Existing Screed

The customer had decided to go with a slightly different shade of tile for the extension as the original front door step had been left in the existing floor and would create an interesting feature between new and original. It turns out that the step penetrated deep into the substrate and could not be removed.

I waited for the new surface to dry before laying out the tiles to find the best layout, then satisfied with the pattern the tiles were fixed in place using a flexible adhesive and grouted in.

Quarry Tiled Floor Extension Blakedown Kidderminster Laying Tiles

Quarry Tiled Floor Extension Blakedown Kidderminster Tiles Laid

The next day we returned to restore the original Quarry tiled floor, firstly using Tile Doctor Remove and Go to break down any old sealer and paint. The product is sprayed on and allowed to dwell for a short time giving it time to penetrate. The product is then worked into the tile and grout using a rotary floor machine fitted with a scrubbing pad. The soil generated is rinsed off the floor with water and extracted using a wet vacuum.

Next, I decided to give the floor an acid wash using Tile Doctor Acid Gel to remove any old grout smears and other mineral deposits that were affecting the appearance of the Quarry tiles. Again, the product was scrubbed in and then removed using water and the wet vacuum. Once that was done the floor was left overnight so it could dry out ahead of the sealing process.

Sealing a Quarry Tiled Hallway Floor

The following day the floor was check for moisture and then sealed with four coats of Tile Doctor Seal and Go Extra. This has a special acrylic-based formula which being fully breathable copes well with locations such as hallways where damp conditions are more likely. Seal and Go Extra also adds a nice subtle sheen to the Quarry tiles which enhanced their appearance and made the difference between the original and new tiles less conspicuous.

Quarry Tiled Floor Extension Blakedown Kidderminster After

The customer was very happy with the new floor and pleased that we had been able to match it so well to the existing.

Source: Quarry Tile Cleaning, Sealing and Tiling Service in Blakedown, Worcestershire

Tired Quarry Tile & Grout Renovated in Outwood, Surrey

Posted on November 10, 2018 by AbzDominise

This client who lived in a property in the Village of Outwood had a tired looking Quarry tiled floor in their lounge and asked if we could improve the look of it. I went over to take a look and can see the tiles were situated in front of a brick fireplace and added a nice rustic feel to the room that was well suited to the house.

Quarry Tiled Floor Before Renovation in Outwood

It had clearly been some time however since the Quarry tiles had been given a good clean and seal; the tiles were looking dull and lifeless and the grout was especially bad and had darkened with the ingrained dirt. I could see a deep clean would be required to lift the dirt out so after discussing the process we agreed a date for me to come back and renovate the floor.

Deep Cleaning Quarry Tile and Grout

When I returned to clean the floor my first task was to protect any areas that may be impacted by the cleaning process which in this case related to the adjacent carpet.

To be able to reach into the pores of the tile and grout and lift out the dirt I needed to remove any remaining sealer. To do this I applied a medium dilution of Tile Doctor Remove and Go which is a strong coatings remover and cleaner that’s ideal for these situations. The product is left to dwell for ten minutes, so it can get to work breaking down the old sealer and dirt and is then scrubbed into the floor. Normally I use a black scrubbing pad fitted to a rotary machine running on slow speed to do this however given the size of the floor I decided to use a deck brush to scrub the tiles and a narrow grout brush along the grout lines.

The soiled cleaning solution was rinsed off the floor with water and extracted using a wet vacuum. I then inspected the floor and spot treated any areas that needed further attention with a repeat of the same process. Once I was satisfied the Quarry tile and grout was as clean as it could be, I left for the night so the floor cold dry off.

Sealing Quarry Tiles

Returning the next day, I sealed the Quarry tiles with several coats of Tile Doctor Seal and Go which adds a nice subtle sheen finish to the tiles and will provide the tiles with long lasting protection. Seal and Go is a water-based sealer so doesn’t leave a smell as it dries which is always a plus.

My client was impressed with the transformation and as I think you will agree the Quarry tiles now look much brighter and the grout has returned to a much lighter shade.

Quarry Tiled Floor After Renovation in Outwood

Source: Quarry Tile Cleaning and Renovation Service in Outwood, East Surrey

Renovating Cloakroom Quarry Tiles in a Worcester Village

Posted on September 23, 2018 by AbzDominise

These photographs are from a beautiful farmhouse in the tranquil village of Brotheridge Green near the city of Worcester. Worcester is famous for many things, Royal Worcester Porcelain, Lea and Perrin Worcester Sauce, Berrow’s Worcester Journal which claims to be the oldest newspaper, and indeed it was also the hometown of the composer Edward Elgar.

Quarry Tiled WC Floor Brotheridge Green Farmhouse Before Cleaning

The owner of the farmhouse asked me to come and look at their downstairs cloakroom which had existing quarry tiles fitted. They were becoming frustrated that they couldn’t get the area to look clean and were considering replacing the floor. The owners of the property had used every cleaning product they could find and scrubbed for hours to try and get these quarry tiles in their cloakroom clean. The problem with the tiles was a build-up of ingrained dirt over time as the tiles had not been sealed, so no amount of cleaning with household products would have helped. There was also an issue with salts rising through the tiles which was making them look worse, common in properties of this age.

Following my inspection, I explained to the customer what I could do to bring the tiles back to life. I completed a quote for the work that evening which they gladly accepted, and the work was scheduled in.

Cleaning a Quarry Tiled Cloakroom Floor

On day one of the job my first step was to sweep away any loose debris from the quarry tiles. I then tackled the floor with Tile Doctor Pro-Clean this is a heavy-duty alkaline cleaner which is safe to use on Tile and Stone, in concentrated form it can strip away sealers and grease and was perfect for this job. As I was working in a confined space I opted to complete the job by hand using a deck brush and scrubbing brush to work the solution in after leaving the Pro-Clean to dwell and soak into the floor for ten minutes. I then extracted the resultant slurry off the floor with my wet and dry vacuum and repeated this process until I was happy the floor was as clean as it could be given its age.

I then finished the cleaning of the floor with an acid rinse using Tile Doctor Acid Gel to remove grout stains and counter potential salt efflorescence issues which are a common problem with these old floors where no damp proof membrane has been installed. The floor was then rinsed again with water, dried with the wet vacuum and left to dry off fully overnight.

Sealing a Quarry Tiled Cloakroom Floor

When I returned the following morning, I checked the floor was dry using my moisture meter; this is important step as a damp floor will effect the ability of the sealer to cure.

I decided to seal the Quarry tiles with Tile Doctor Seal and Go Extra, which is a semi-gloss breathable sealer to allow for any damp issues and applied four coats allowing each coat to dry for approximately 30 minutes before adding the next. This gave a nice natural finish letting the colour of the quarry tiles shine through.

Quarry Tiled WC Floor Brotheridge Green Farmhouse After Cleaning

The customer was very happy with the result and is looking to get the rest of the Quarry tiles in the house cleaned and sealed in the future. They were very happy that the floor didn’t need to be replaced.

Source: Quarry Tile Cleaning and Sealing Service in Brotheridge Green, Worcestershire

Improving the Red & Black Colour of a Quarry Tiled floor in Buxton, Derbyshire

Posted on July 18, 2018 by AbzDominise

The photographs below are from a client who lives in an older property in Buxton which you may have heard of due to its famous spa and popular spring water. Buxton is situated in the county of Derbyshire, in the East Midlands and has the highest elevation of any market town in England.

The property had Red and Black Quarry tiles laid throughout the Kitchen and the downstairs in a diamond pattern. Quarry tiles are very hard wearing and thus a popular and traditional flooring option for high traffic areas in the past. Certainly, in this case they were in good physical condition given their age and they looked very much in-keeping with the period property along with the fireplaces.

Red Black Quarry Tiled Floor Before Cleaning Buxton

The client loved the feature floor but felt the tiles were looking neglected and they were struggling to keep them clean. This is a common problem with quarry tiles which are porous and need to be sealed to keep them looking good, however over time the sealer wears down with use and dirt becomes ingrained in the pores of the tile making them impossible to clean effectively. The client just wanted them to look clean and ensure they could be easily maintained.

I recommended deep cleaning the tiles to remove the dirt and the sealing them to protect them going forward a process which usually takes around two days.

Cleaning and Restoring Quarry tiles

My quote was accepted, and I returned on the agreed date to complete the work starting with the first part of the process which involved removing the ingrained dirt, grime and any remaining sealer that may be present on the floor. To do this I applied a strong dilution of Tile Doctor Pro-Clean and left it to dwell for ten minutes. The Pro-Clean was then worked into the tile and grout using a black buffing pad fitted to a rotary machine. Once done the now soiled cleaning solution was rinsed off the floor with water and a wet vacuum was used to extract it from the floor. Some areas of tile were stained with paint slashes from decorating and these was spot treated with Tile Doctor Nanotech HBU which stands for Heavy Build-Up remover and is pretty good at dealing with all sorts of stains and tough soiling on tiled floors. The floor was then dried using the wet vacuum and left overnight to allow it to dry out thoroughly.

Sealing Quarry Floor Tiles

The client had left the radiators on overnight to aid the drying process and by the next morning the floor was nice and dry. I tested the moisture content to be sure and it was well within acceptable levels and therefore ready for the next stage. It’s important to ensure the tiles are dry before applying a sealer as the sealant won’t cure and the result will be compromised.

I sealed the floor a couple of coats of Tile Doctor Colour Grow sealer. I chose this product because the house had some damp problems due to its’ age and I decided a breathable fully sealer was the best option for this situation as this will allow moisture to rise-up through the tile and evaporate without causing any problems. Colour Grow works by soaking into the pores of the tile protecting it from within and improving the natural colours of the tile in the process.

Red Black Quarry Tiled Floor After Cleaning Buxton

The end result was the floor looked much cleaner and colours in the tiles were more vibrant, needless to say my client was very pleased with the result and the sealer will ensure the floor is easy to maintain floor for the future as per their brief.

Source: Quarry Tile Cleaning and Sealing Service in Buxton, Derbyshire

Painted Quarry Tiled Floor Restored in Whaley Bridge, Derbyshire

Posted on February 28, 2018 by AbzDominise

This was an unusual Quarry Tiled Floor that I was asked to renovate at a house in Whaley Bridge which is a small town in Derbyshire Peak district. The floor tiles were laid in a diamond pattern using alternating Black & Red quarry tiles. The house was more than 100 years old and recently changed hands. A large rug had previously occupied the middle of the floor and the tiles around the side has been painted over with black paint.

Old Black and Red Quarry Tiled Floor Before Cleaning Whaley Bridge

To restore the floor to a consistent appearance I could see the paint would need to be removed and then the whole floor given a deep clean and seal. Additionally, there was an old Fireplace at one end of the room decorated in antique Ceramic tiles that needed cleaning, the Tiles are very old but in good physical condition for their age.

Old Ceramic Tiled Fireplace Hearth Before Cleaning Whaley Bridge

Cleaning Old Black and Red Quarry Tiles

My first task was to remove the black paint and years of ground in dirty by treating the tiles with a poultice made from two Tile Doctor products namely Nano-Tech HBU Remover and Remove and Go. Working in sections the solution was applied to the tiles and left to soak in for a good twenty minutes before scrubbing with a rotary machine fitted with a black scrubbing pad running at slow speed.

The resulting soil was extracted using a wet vacuum and then the tiles rinsed with water, so I would see where more work was needed. Stubborn stains were then spot treated with the same process before moving onto the next section. The Ceramic tiles in the fireplace hearth was treated in the same way.

After removing all the dirt, stains and paint I gave the floor a final rinse to remove any trace of cleaning product and extracted as much moisture as possible using the wet vacuum. The floor would need to be dry before applying a sealer, so to allow the floor to fully dry off I left the floor for two days.

Sealing Original Quarry Hallway Tiles

On my return I checked the tiles first to ensure they were dry. All was good so I set about applying a couple of coats of Tile Doctor Colour Grow which is a colour enhancing impregnating sealer that occupies the pores in the clay. Additionally, Colour Grow is a breathable sealer which is important for these old floors that don’t have a damp proof course. There was no need to apply the sealer to the ceramic tiles in the hearth however as they won’t take a sealer due to the glaze.

Old Black and Red Quarry Tiled Floor After Cleaning Whaley Bridge

Once completed the floor looked completely transformed and the client was more than happy. Work continues in other parts of the house and once they have finished decorating they have asked me to return to restore their beautiful old Victorian tiled hallway.

Old Ceramic Tiled Fireplace Hearth After Cleaning Whaley Bridge

Source: Quarry Tile Cleaning and Renovation Service in Derbyshire

Rebuiling a Damaged Quarry Tiled Floor in Croydon

Posted on February 1, 2018 by AbzDominise

There is perhaps nothing more irritating for a homeowner than to discover a leaking pipe. Even worse still is when that leak occurs underneath a natural stone floor!

This recent customer of mine, who lives in Croydon, had unfortunately discovered a leaking pipe underneath her Quarry tiled kitchen floor. The plumbers had dug a trench in the floor to replace the pipe and fix the problem. As you can see in the photos below, the original tiles were not replaced and the entire floor was generally left in a bit of a mess.

Quarry Tiled Floor Before Rebuild Croydon

The customer had been trying to find a professional company to restore the floor, but her insurance company would only agree to sending normal cleaning companies to the job. Given the reality of the situation, you won’t be surprised to know that these companies all politely refused!

The situation went unresolved for over six months before the customer finally decided to contact Tile Doctor to restore the floor.

Rebuilding and Cleaning a Quarry Tiled Floor

The restoration took place over the space of six days. Our first port of call was to replace the tiles that had been removed as part of the plumbing work. This wasn’t the easiest process as we had to level up the floor before the tiles could be replaced.

Making matters more complicated, the tiles were all hand-made, and it was a bit like completing a jigsaw to avoid lippage. Lippage – for those unfamiliar with the term – means when a floor is laid unevenly and it can make walking on it hazardous.

Quarry Tiled Floor During Rebuild Croydon

Once the tiles were reinstalled, it was time to give the whole floor a deep clean. For this, we used Tile Doctor Oxy Gel, leaving it to dwell on the surface for around ten minutes, before scrubbing it into the stone in combination with hot water. Oxy Gel is a strong, alkaline-based cleaner which works effectively to break down dirt and grime, as well as old sealers and waxes.

The next stage of the restoration was to rinse the floor with fresh water, and then lay down Tile Doctor Acid Gel for 15 minutes. Acid Gel is a blend of phosphoric and hydrochloric acids in gel form which is used to neutralise any grout haze and efflorescence on the tiles.

Sealing a Quarry Tiled Floor

After completing the deep cleaning process, we rinsed the floor again with fresh water and then left it to dry for three days. Giving the floor enough time to dry was important, since any excess moisture would not have allowed us to complete the restoration by sealing the tiles.

After a few days, however, the floor was indeed thoroughly dried and could receive a fresh seal. We sealed the floor using five coats of Tile Doctor Seal and Go, a topical sealer which eliminates traditional two-step sealing methods. What this means is that it provides both a robust surface seal and a high-quality low sheen finish – in one product.

After six months of difficulty and disruption, the customer was very happy to have her Quarry floor completely restored in just six days. Check out the photos below to see the outcome.

Quarry Tiled Floor After Rebuild Croydon

Source: Quarry Tile Cleaning and Sealing Service in Croydon, South-London

Removing Carpet Glue from Quarry Tiles in West Surrey

Posted on November 30, 2017 by AbzDominise

Dunsfold is a very small village in the borough of Waverley in West Surrey. It’s well known for the Dunsfold Aerodrome, an airfield that was built by the Canadian army during World War II. Hundreds of years ago, members of the English aristocracy held large estates of land in and around Dunsfold – and several historic cottages still exist in the area.

A customer of mine had recently bought one of these cottages and, during renovation work, had removed the downstairs carpets in three rooms to discover a Quarry tiled floor. Naturally, they were caked in many years’ worth of muck and carpet glue.

It would be a significant job to get the tiles in the three rooms back to looking their best – but it was a job I was more than willing to undertake. Classic Quarry tiles exude a certain rustic quality and charm – a welcome addition to many vintage properties, especially those located out in the countryside.

Quarry Tiled Floor Before Renovation at Dunsfold Cottage

Deep Cleaning a Quarry Tiled Floor

I started the restoration by soaking small areas of the floor in Tile Doctor Remove and Go. This product is excellent for removing floor coatings such as old sealers as well as shifting stubborn filth and loosening carpet adhesive deposits. After carefully scraping any excess adhesive off manually with a sharp blade, I ran my buffing machine across the floor and immediately the tiles cleaned up well.

Next, I used a 200-grit (Coarse) diamond-encrusted burnishing pad on the floor. This basically skims a layer off the tile surface, revealing the original colour of the stone that had previously been hidden underneath. A small amount of water was used as lubrication for this process. Quarry tiles are naturally very porous so after rinsing the soil off the floor I left them over the weekend to dry.

While the somewhat aggressive approach of burnishing is highly effective, it can leave the tiles looking a little washed out – and the colour slightly diminished. However, I assured the customer that the colour would return once the tiles had been sealed.

Sealing an Original Quarry Tiled Floor

While I was enjoying my weekend off, the customer fortunately found a few replacement Quarry tiles in his attic to fit around the fireplace as upstands where there were some tiles missing. So, on my return to the property my first task was to fit these replacements, before sweeping the floor clear of any debris.

To finish the restoration, I applied a couple of coats of Tile Doctor Colour Grow, an impregnating sealant which provides the matte, natural-look finish the customer wanted. This sealant penetrates into the pores of the tile, so it dries inside the stone not on the surface. It also intensifies the fantastic red shades in the Quarry.

Quarry Tiled Floor After Renovation at Dunsfold Cottage

Around an hour after the coats of Colour Grow had been applied, the floor was dry and free to be walked on, and all the furniture could be returned. Much needed life and character had been restored to the Quarry tiled floor and the new property owner was very happy as a result.

Source: Quarry Tile Cleaning and Restoration Service in Dunsfold, West Surrey

Stripping Wax and Paint for Quarry Tiles in Cheltenham

Posted on November 23, 2017 by AbzDominise

It’s often quite surprising what condition we find some tiles in when were asked to come out and survey the floor. Case in point being this Quarry tiled kitchen floor I was asked to look at by a customer in Cheltenham, which as you may know is particularly famous for its racecourse and the top-secret GCHQ.

Upon arrival at the property, I found that the floor was not in great condition. For some reason, it had been painted over with red tile paint and then covered with a wax coating which was easily scratched. To Make the situation worse, there were around 20 tiles in the floor with holes in them that had simply been filled with concrete.

Quarry Tiled Floor Cheltenham Before Removing Paint

Clearly, the tiles had not been maintained properly in the past but fortunately the current owner of the property who was keen to have them restored had called in Tile Doctor and after a demonstration clean I was booked to come back and correct the numerous issues.

Cleaning a Damaged Quarry Tiled Kitchen Floor

On the first day of the restoration, I started by applying a solution of Tile Doctor Remove and Go across the entire floor and leaving the product to dwell for around 30 minutes. Remove and Go is a powerful stripper designed to loosen paint splashes, adhesive stains and many types of urethane and wax coatings so that they can be easily removed.

After leaving the product to dwell, I could use a handheld scrapper to simply remove the wax coating and layer of paint on the floor. This process took about half a day; during the second half of the day, I spent my time removing the damaged tiles and replacing them with new Quarry tiles that had been sourced to match nicely with the existing floor.

On the second day, any stubborn paint splashes remaining were re-treated and I subsequently deep cleaned the floor using a strong dilution of Tile Doctor Pro-Clean. This strong alkaline cleaning product was worked into the tiles using a 17-inch scrubbing pad fitted to a specialised rotary machine. The resultant soil was extracted off the floor using a wet vacuum and given a rinse with water to neutralise the floor. The wet vacuum was used again to remove the water and extract as much moisture from the tiles as possible to improve the drying time.

Sealing a Quarry Tiled Kitchen Floor

Once the deep clean had been completed, I left the floor dry for two days to allow sufficient time for it to dry thoroughly. Upon returning to the property, I ran a damp test to see if the tiles were dry enough to be sealed. To my surprise, the floor recorded only around 4% moisture even though the property is relatively old and is unlikely to have a damp proof membrane installed.

Nonetheless, this meant I could seal the floor. I did this by using a single coat of our impregnating, colour-intensifying sealer known as Tile Doctor Colour Grow, followed by three coats of Tile Doctor Seal and Go, a water based sealer which provides a high-quality satin finish.

Quarry Tiled Floor Cheltenham After Cleaning and Sealing

The deep clean, combined with the application of two different sealers, really helped to give these Quarry tiles a new lease of life. The customer was very happy indeed – in fact, had this been an exam, I’m certain I would’ve received top marks and it was certainly a major improvement on how they were before.

Source: Quarry Tile Cleaning and Renovation Service in Gloucestershire

Quarry Tiled Hallway Restoration in Surrey

Posted on November 2, 2017 by AbzDominise

As the West Surrey Tile Doctor I cover quite a large area including Haslemere which is a town on the South-Western edge of the county in the borough of Waverley. I was down there to visit a customer who had recently bought an old property there and during the renovations uncovered six foot of quarry tiles by the front door. There was a patch of concrete that also needed investigating.

Quarry Tiled Floor Before Cleaning Haslemere

Cleaning Hallway Quarry Tiles

I began by carefully removing the layer of concrete with a scraper and a covering of Tile Doctor Acid-Gel hoping it would expose more quarry tiles underneath. Sadly, this wasn’t the case and all I exposed was an area of ruined quarry tiles and four buried bricks. These would have to be removed then filled to bring them to the same level as the remaining tile so I could lay new tiles their place. A couple of noisy hours later following drilling and violent chisel work I’d removed enough to lay flat tiles.

I spent the next hour cleaning and preparing the remaining good tiles. After years of being covered by carpet there was a fair amount of adhesive to remove. This was loosened with Tile Doctor Remove and Go and small abrasive hand-held Diamond blocks to get into the corners.

The Remove and Go was applied to the tiles, left to soak in for ten minutes and then worked into the tile and grout with a stiff brush. The then the soiled solution was rinsed off and extracted using a wet vacuum. Following this work the tiles looked clean but worn out and colourless which is not unusual for this stage of the process and would be resolved once a sealer had been applied.

Tiles were then cut to measure then fixed in place with a rapid adhesive in line with the originals. Once they had set they were grouted in with a grout that closely matched the original. The rest of the floor was inspected at this point and any holes filled with more grout until flat. The grout and tiles were left to dry which was a good opportunity for me to eat lunch.

Sealing Original Quarry Tiles

It was only a small area so later that afternoon the tile and grout and I was able to finish the restoration with the application of two coats of sealer. On this occasion I chose to use Tile Doctor Colour Grow which is an impregnating sealer that soaks into the pores of the clay Quarry tiles protecting them from within and also enhancing the red colours in the tile.

The result was a significant improvement and the customer was very happy, leaving the following testimonial on the Tile Doctor feedback system.

“Rupert was absolutely brilliant. Very friendly and professional, worked cleanly and totally rejuvenated our quarry tile entryway. Would definitely call him again and recommend to friends.”

Source: Quarry Tile Cleaning and Restoration Service in Surrey

Cleaning a Quarry Tiled Kitchen at a Listed Building in Devon

Posted on October 18, 2017 by AbzDominise

This story follows on from a previous post on the renovation of a Victorian Tiled Reception Area at a listed Georgian Townhouse in the middle of the small market town of South Moulton in North Devon. You may recall he was struggling to clean the floor in the reception area and I was called in to sort it out. Whilst I was there he also asked me to deep clean and seal the Kitchen Quarry Tiles.

Kitchens as you can imagine are one of the busiest areas in any house and as a result the floors do see a fair amount of wear; in this case the Quarry tiles were dull and lifeless and I suspect any previous sealer had long since worn off.

Quarry Tiled Kitchen Floor Before Cleaning South Molton

Cleaning Kitchen Quarry Tiles

The Quarry tiles were in a better state than the Victorian tiles I discussed in the previous post so a less aggressive course of action was required. In this case I applied a strong dilution of Tile Doctor Pro-Clean and left it to soak in. Pro-Clean is an effective tile cleaner which will clean and strip off old sealers in a strong dilution. This was important as I wanted to be sure any remaining sealer would be removed, typically sealers wear off in the high use floor areas first so it was quite possible some sealer would still be present on the less used parts of the floor.

After ten minutes I agitated the solution with a black scrubbing pad fitted to a rotary scrubbing machine to really get the floor clean and then rinsed off the soiled cleaning solution with water and a wet and dry vacuum before leaving it overnight to dry off fully.

Sealing Kitchen Quarry Tiles

The following day I returned and after rechecking the moisture levels to ensure that they had adequately dried out I started to seal the Quarry tiles in the Kitchen using Six coats of Tile Doctor Seal and Go which leaves a satin finish once dried and gives the tiles a freshly mopped or slightly glazed look.

Quarry Tiled Kitchen Floor After Cleaning South Molton

The customer was thrilled and left the following feedback on the Tile Doctor feedback system:

“The work was carried out in a professional manner, with excellent results.”

For aftercare I left the customer with some guidance on care and maintenance of the floor as well as a suitable bottle of tile cleaner.

Source: Quarry Floor Tile Cleaning and Sealing Service in Devon

Maintaining a Victorian Quarry Tiled School Floor in Northamptonshire

Posted on August 1, 2017 by AbzDominise

It was back in 2013 that I first visited this school in Oundle to attend to a 150-year old Victorian Quarry tiled floor which, at the time, had extensive problems with damp and a poor performing sealer that had gradually peeled away.

Victorian Quarry Tiles Oundle School in 2012

Over a few weeks, we successfully stripped away the old and ineffective sealant and addressed the damp issues, before applying a breathable sealer. We subsequently allowed the tiles to successfully dry out for several months before returning to the school to provide a light clean and apply our topical sealer, known as Tile Doctor Seal and Go, as the school required a shiny, yet hard-wearing finish.

I posted a story on my website about this original job, which you can see here:

150 Year Old Quarry Tile Restoration in Northants School

As part of my initial visit, I had supplied the school with five litres of Tile Doctor Neutral Tile Cleaner, which is a pH neutral formula designed for regular use, and a white buffing pad. I had also spent an hour with their in-house cleaner (who was already familiar with using a buffing machine) to talk through daily maintenance of the floor, as over 100 children can be walking over these floors at any one time on an almost daily basis.

Of course, not every floor will receive this amount of traffic and suffer from this level of wear and tear, but in these situations Tile Doctor can offer a maintenance plan for our customers.

Victorian Quarry Tiles Oundle School in 2013

Cleaning and Sealing Quarry Tiles for Maintenance

The school have me back annually to carry out a full maintenance clean and seal. This involves, firstly, etching the top coats of sealant with a green diamond-encrusted burnishing pad to remove any build-up of dirt and staining. Then, I rinse the whole floor with fresh water and soak up the residue with a wet vacuum.

After drying the area with fans, I proceed to reapply two fresh coats of Tile Doctor Seal & Go. This is now my fourth year of visiting the school and, as the photos show, an annual maintenance plan is the best way to keep floors in top condition without the disruption caused by a full clean or restoration.

Victorian Quarry Tile After Maintenance Oundle School in 2017

Contact your local Tile Doctor consultant about the maintenance plan we offer for any natural stone flooring after an initial clean.

Source: Tile Cleaning and Maintenance Service in Northamptonshire

Careful Cleaning of Quarry tiles around a swimming pool

Posted on June 16, 2014 by AbzDominise

Photographs below of a job we did cleaning and sealing the Quarry Tiles surrounding a residential indoor swimming pool floor tiles at a grand residence in Cambridge. As you can see from the photograph below the Quarry tiles and Grout was looking rather washed out and given their proximity to the pool extra care was needed to be ensure we didn’t contaminate the pool with dirty water from the cleaning process or chemicals, fortunately all our equipment is electrically isolated so that was not a problem.

Quarry Tiled Pool Surround Cambridge Before Cleaning

Swimming Pool Tile Cleaning

Fortunately the pool was fitted with a cover so we made a start cleaning the tiles using a strong dilution of Tile Doctor Pro-Clean mixed 50/50 with NanoTech Ultra Clean which add tiny abrasive particles into the cleaning solution making it more effective. Working in sections the solution was left to soak into the tile and grout before being worked into the floor using a rotary machine fitted with a scrubbing pad running at slow speed to reduce splashing. This process removed any remaining sealer and cleaned the tile and grout up nicely, we used clean water to rinse the floor and a wet vacuum to remove the soiled solution making sure not to drain any solutions into the pool and re-treating any stubborn areas. This process was fairly tedious and took up much of the day but the results were well worth the effort.

Quarry Tiled Pool Surround Cambridge After Cleaning

Sealing Quarry Tiles around a Pool

The tiles were left to dry off overnight and we came back the next day to seal the floor using two coats of Tile Doctor Colour Grow which is an impregnating sealer that fills up the pores in a tile to protect it from stains whilst enhancing its natural colours.

Quarry Tiled Pool Surround Cambridge During Sealing

The process worked well and you can see the difference in the photographs above however the tricky nature of the environment meant it took longer than usual to complete but the main thing was the customer was happy with the result.

Quarry Tiled Pool Surround Cambridge After Sealing

Source: Quarry Tiled Pool Surround Cleaned and Sealed in Cambridge

Deep Cleaning Grubby Quarry tiles

Posted on June 14, 2014 by AbzDominise

This Quarry Tiled Kitchen floor had been laid in 2000 which is relatively recent compared to some of the floors I’m asked to deal with, the tiles are 150 x 150 mm Quarry tiles with a mixture of colours. A customer in Cardiff said that the Quarry tiles has been sealed by the tiler however it wasn’t long after it was completed that the before became very grubby looking. You can see this for yourself in the photograph below where you should be able to make out the ingrained dirt and discoloured tile grout.

Grubby Quarry Tiled Kitchen Floor Cardiff Before Cleaning

Cleaning Quarry Tiles

I set about cleaning the floor with undiluted Tile Doctor Remove and Go mixed 3 to 1 with NanoTech UltraClean which adds tiny abrasive particles to a strong coatings remove; this mixture not only removes any previous sealers but also deep cleans the tiles and brings the grout back to its original colour. I used a rotary machine with a disc shaped scrubbing brush attachment disc which really gets into the dirt. The soiled solution was removed using a wet vacuum, stubborn areas retreated and then the floor was rinsed until all the cleaning solution had been removed.

Grubby Quarry Tiled Kitchen Floor Cardiff During Cleaning

Sealing a Quarry Floor Sealing

The floor was left to dry for 24 hours and I came back later to seal it. Before sealing I used a hand held damp meter to verify the floor had dried. I had previously discussed the choice of sealer with the customer to establish how they wanted the floor to look and selected Tile Doctor Seal and Go for its satin shine.

Grubby Quarry Tiled Kitchen Floor Cardiff During Sealing

I went on to seal the tiles with two coats of Tile Doctor Seal and Go using a water test to verify I had applied the right amount of sealer and that liquids were being repelled from the surface of the tile as opposed being absorbed.

Grubby Quarry Tiled Kitchen Floor Cardiff After Cleaning and Sealing

The floor cleaned up really well especially after sealing which brought the colours in the tile back to life; the customers were delighted with the results.

Source: Residential and Commercial Tile Cleaning in South Wales

Restoring Varnished Quarry Tiles

Posted on April 3, 2013 by AbzDominise

This Quarry tiled hallway installed in a house in South West London had been varnished many years previously and was worn through leaving a dark and uneven appearance and difficult to clean.

Cleaning the Quarry Tiled Floor

We started cleaning the Quarry Tiles by applying a strong solution of Tile Doctor Pro-Clean worked into the floor using a buffing machine fitted with a black scrubbing pad. Although this had an effect on the Varnish it was proving difficult to shift so using a scraper tool it was manually scraped off the floor. The floor was washed down with clean water and then cleaned again using Pro-Clean before finally washing down three more times using clean water in order to neutralise the floor and remove any trace of cleaning products before sealing.

Sealing Quarry Floor Tiles

The floor was left to dry overnight and I came back the next day to apply the sealer. For sealing the Quarry tiles I used five coats of Tile Doctor Seal and Go, it’s recommended for Quarry tiles and adds a nice low sheen to the floor; sealing does take time as it’s necessary to allow each coat to dry before applying the next so it took most of the day to complete the job. You can see the difference in the floor which has come up a lot lighter and is now much easier to maintain.

Quarry-Tiled Hallway after cleaning and sealing

Source: Quarry Tile Cleaning in London SW11

Quarry Tiled Floor in a Public House Cleaned and Sealed

Posted on March 17, 2013 by AbzDominise

Great set of photographs here for a client in Boston this time in an old Public House. The floors were made up of stone and quarry tiles and looked to be over 100 years old, there was no evidence of a sealer being applied and they were in need of a good clean.

Cleaning Quarry Tile Flooring

To start the Quarry tile cleaning we set about giving the floor a good scrub using Tile Doctor Pro-Clean and a rotary machine fitted with a buffing pad. We find machines can take a lot of the work out of the job but can only do so much, to reach those tricky corners you have to get down on your hands and knees with a scrubbing brush and add a bit of elbow grease. We worked at it for much of the day finishing by washing the floor down with clean water to remove any remaining chemical and neutralise the floor ready for sealing.

Sealing the floor with a Quarry Tile Sealant

We let the floor dry overnight and came back the next day to apply the sealer. For this we used Tile Doctor Seal and Go which is ideal for older Quarry Tile floors which were probably laid without any form of damp proofing, the sealer is water based and as well as bringing out the colour in the tile and providing protection it allows the transmission of moisture vapour up though the floor.

The Quarry Tile floor required 4 coats of Seal and Go to get the job done, we find it always best to do a water test to discover if the right amount of sealer has been applied as too much will lead to the floor going sticky. To do this you wait for the sealer to dry and add a drop of water to the top of the tile, if the drop sits on top of the tile in a bubble then enough sealer has been applied.

Needless to say the customer was delighted with the results and the pub is now open for business.

Source: Cleaning Quarry Tile at a Public House in Boston
